DS200AAHAH1A控制系统备件可控硅模块使用配置教程工控卡件PLC/DCS备件模块

DS200AAHAH1A是用于Mark V LM系列Speedtronic硬件的GE ARCNET 连接板(AAHA)

DS200AAHAH1A是一块PCB，能够充当接口单元，将各种IO内核或外部设备连接到<R> 控制引擎。AAHA提供与ARCNET的连接。<R>内核中使用了两块AAHA板。一个充当<R>核心和用户界面的中间人。APL连接器将此板连接到位于<R>内核中的UCIA板上的UCPB子板。第二个用作将COREBUS连接到<R>核心的方法。它还促进了IO内核与<R>内核中的<R>控制引擎之间的通信。该板上的APL连接到PANA子板。
DS200AAHAH1A是一个小型PCB，顶部有3个通信端口。左侧端口不经常使用，标记
为EBNC端口。EBNC旁边是ARCBNC-A和ARCBNC-B端口，它们是ARCNET通信的连接。右下角是一个2针2PL连接端口。中央是一个APL 10针连接端口。此端口能
够提供一种与具有ARCNET驱动程序且位于<R>核心中的板进行通信的方法。左下角的9针EPL连接也未使用。

DS200AAHAH1A Control System Spare Parts Controllable Silicon Module Usage and Configuration Tutorial Industrial Control Card PLC/DCS Spare Parts Module
DS200AAHAH1A is a GE ARCNET connector board (AAHA) used for Mark V LM series Speedtronic hardware
DS200AAHAH1A is a PCB that can act as an interface unit to connect various IO cores or external devices to the<R>control engine. AAHA provides connection with ARCNET< R> Two AAHA boards are used in the kernel. A middleman who acts as the<R>core and user interface. The APL connector connects this board to the UCPB sub board located on the UCIA board in the<R>kernel. The second method is used to connect COREBUS to the<R>core. It also facilitates communication between the IO kernel and the<R>control engine in the<R>kernel. The APL on this board is connected to the PANA sub board.
DS200AAHAH1A is a small PCB with three communication ports on the top. Left port not frequently used, marked
For EBNC port. Next to EBNC are the ARCBNC-A and ARCBNC-B ports, which are the connections for ARCNET communication. The bottom right corner is a 2-pin 2PL connection port. The center is an APL 10 pin connection port. This port can
Provide a method for communicating with boards with ARCNET drivers located in the<R>core. The 9-pin EPL connection in the bottom left corner is also not used.
