CAMERON AAP3798102-001 30通用显示压缩机控制模块便用通用接线板或接线板将接线板安装在控制外壳内，并将屏蔽电缆从接线板连接到模块接线板端子上的每个输入电路。将每根电缆的屏蔽连接到接线板旁边的金面板。不要在模块端连接屏蔽在电缆模块端切断屏蔽并用热缩管绝缘。用屏蔽电缆将现场设备连接到端子板，仅在设备端接地屏蔽在电缆的端子板端切断屏蔽并用热缩管绝缘。
AAP3798102-00130
此外,应尽可能缩短端子板和设备端的外露屏蔽外部引线的长度。直接方法将屏蔽电缆从现场设备传感器、电位计等直接连接到模块。将导体连接到模块端子板上的适用螺钉上。将现场设备端的屏蔽接地，使最小数量的导体暴露在噪声环境中。不要在模块端连接屏蔽切断电缆模块端的屏蔽并用热缩管绝缘。CAMERON AAP3798102-001 30TBQC不推荐用于模拟模块由于电缆屏蔽要求，端子板快速连接TBQC组件不建议用于模拟模块。
AAP3798102-00130
CAMERON AAP3798102-001 30 Universal Display Compressor Control Module uses a universal terminal block or terminal block to install the terminal block inside the control housing, and connects shielded cables from the terminal block to each input circuit on the module terminal block terminals. Connect the shielding of each cable to the gold panel next to the terminal block. Do not connect the shield at the module end. Cut off the shield at the cable module end and use heat shrink tubing for insulation. Connect the on-site equipment to the terminal board using shielded cables, and only ground the shielding at the equipment end. Cut off the shielding at the terminal board end of the cable and insulate with heat shrink tubing.
AAP3798102-00130
In addition, the length of the exposed shielding external leads on the terminal board and equipment ends should be minimized as much as possible. Directly connect shielded cables from on-site equipment sensors, potentiometers, etc. to modules. Connect the conductor to the applicable screw on the module terminal board. Ground the shielding of the on-site equipment end to expose the minimum number of conductors to a noisy environment. Do not connect the shielding cable at the module end and cut off the shielding at the module end, and use heat shrink tubing for insulation. CAMERON AAP3798102-001 30TBQC is not recommended for analog modules. Due to cable shielding requirements, quick connection of terminal boards to TBQC components is not recommended for analog modules.
