IS220PAICH1B型号由通用电气公司生产，是MarkVI系列的模拟输入/输出组件。该型号是PAIC装置的第二个版本，与前一版本的PAIC包相比，其最低工作电压不同。该特定装置的最低电压为22.5伏直流电。该型号使用的标称电源是24或28伏直流电。虽然l5220PAICH1B组件用于MarkVI系列，但它也可以与一些附件(也称为端子板)一起使用;与该特定模拟I/O组件一起使用的端子板都是IS200板，分别是IS20O0TBAIH1C、IS200TAIH1 A和lS20OTAIH2A。
IS220PAICH1B
IS20OTBAIH1C型号是一个屏障型接线盒，当与IS220PAICH1B组件连接和使用时，要求最小电线尺寸为22AWG。使用该型号时，会出现特定的警报，其中一个警报标记为82-83，主要针对输出，表明IS22OPAICH1B组件内的自杀继电器不起作用。该警报的可能原因通常是组件中的自杀继电器命令与相关反馈不匹配、硬件出现故障或采集板上出现继电器故障。这个问题的主要解决方案是更换/O包本身。
IS220PAICH1B
The IS220PAICH1B model is produced by General Electric Company and is an analog input/output component of the MarkVI series. This model is the second version of the PAIC device, and its minimum operating voltage is different from the previous version of the PAIC package. The minimum voltage for this specific device is 22.5 volts DC. The nominal power supply used in this model is 24 or 28 volts DC. Although the l5220PAICH1B component is used in the MarkVI series, it can also be used with some accessories (also known as terminal boards); The terminal boards used with this specific analog I/O component are all IS200 boards, namely IS20O0TBAIH1C, IS200TAIH1A, and lS20OTAIH2A.
IS220PAICH1B
The IS20OTBAIH1C model is a barrier type junction box that requires a minimum wire size of 22AWG when connected and used with the IS220PAICH1B component. When using this model, a specific alarm will appear, one of which is labeled 82-83, mainly for the output, indicating that the suicide relay inside the IS22OPAICH1B component is not working. The possible causes of this alarm are usually a mismatch between the suicide relay command in the component and the relevant feedback, hardware failure, or relay failure on the acquisition board. The main solution to this problem is to replace the/O package itself.
IS220PAICH1B
