GE继电器输出板DS200TCRAG1ACC装有30个插入式继电器。它还有4个34针连接器和4个12针连接器。分配给34针连接器的id是JOR、JOS.JOT和JO。分配给12针连接器的id是JS3、J54、JS5和JS6。由于GE继电器输出板DS20OTCRAG1ACC上有多个连接器，因此必须遵循指南，以确保可以快速将电缆连接到替换板上的正确连接器。在开始更换之前，请确保知道驱动电流紧急切断装置的位置。此外，必须了解如何操作关闭装置，并确认其处于良好的工作状态。熟悉传动装置安装的人员将获得有关电源和紧急切断的详细信息。
DS200TCRAG1ACC
下一步是验证硬盘周围区域的地板是否干净，没有湿气或积水。使用清洁剂清除地板上的油污。还应该移除所有未接地的双头电源线，因为有触电的危险。GE DS200TCRAG1ACC 继电器输出板最佳做法是通知工作区域内其他设备的操作人员和管理人员，工作已经安排好，以便他们能够为工作中断做好计划，并制定应对计划。在硬盘附近选择一个干净、平坦且坚固的工作空间，将装有主板的盒子放在上面。
DS200TCRAG1ACC
The GE relay output board DS200TCRAG1ACC is equipped with 30 plug-in relays. It also has four 34 pin connectors and four 12 pin connectors. The IDs assigned to the 34 pin connector are JOR, JOS.JOT, and JO. The IDs assigned to the 12 pin connector are JS3, J54, JS5, and JS6. Due to multiple connectors on the GE relay output board DS20OTCRAG1ACC, guidelines must be followed to ensure that the cables can be quickly connected to the correct connectors on the replacement board. Before starting the replacement, make sure to know the location of the emergency cut-off device for the driving current. In addition, it is necessary to understand how to operate the shut-off device and confirm that it is in good working condition. Personnel familiar with the installation of transmission devices will receive detailed information about power supply and emergency shutdown.
DS200TCRAG1ACC
The next step is to verify that the floor around the hard drive is clean and free from moisture or accumulated water. Use a cleaning agent to remove oil stains from the floor. All ungrounded double ended power cords should also be removed as there is a risk of electric shock. The best practice for the GE DS200TCRAG1ACC relay output board is to notify the operators and managers of other equipment in the work area that the work has been arranged so that they can plan for work interruptions and develop a response plan. Choose a clean, flat, and sturdy workspace near the hard drive and place the box containing the motherboard on top.
DS200TCRAG1ACC
