特征：事件计数 – 高达 4 GB 事件编程输出 – 多达 24 个离散输出板载 15 MHz 68HC000 处理器ANSI/IEEE 标准 754-1985，用于 32 位浮点运算VMIVME-2540 是一款智能数字输入/输出板，带有 VMEbus 从机接口，可选择提供 4、8、16 或 24 通道的数字信号测量和信号生成功能。这些测量和信号输出功能由一系列 AM9513A 系统时序控制器 （STC） 和相关接口逻辑实现。板载 VMIVME-2540 本地 CPU（68HC000 微处理器）通过提供命令驱动的用户界面来执行电路板功能，使用户无需直接对系统时序控制器进行编程。用户通过由命令、命令状态、参数和返回测量组成的简单存储器映射界面为每个通道配置测量、定时和输出功能。VMIVME-2540是由通用电气的工业自动化生产系列开发和生产的。这些型号随后被阿巴科系统公司购买。
VMIVME-2540
该系列被称为VMIC/GE Fanuc板，专为工业生产线的几个应用而设计，如CPU管理和输入输出通信。VMIVME-2540是VMIC/GE发那科板的特定模块之一，配备了作为智能计数器控制器操作的功能。此设备最多可计数4千兆事件。它配备了一系列24个离散输出通道，可以通过各种板载跳线模块选项进行编程。这些跳线能够在各种极端电压水平下发挥作用24个输出通道被设计为提供12位分辨率。它们能够以+/-10V的速率产生和吸收高达10毫安的电流。为了使用VMIVME-2540进行离线测试，模拟输入被设计为与外部电路断开连接。VMIVME-2540模块设计有VMEbus从接口，能够提供4、8、16或24通道的数字信号测量和信号生成能力。这些可能的测量和信号输出功能由集成系统时序控制器阵列以及一系列相关接口逻辑应用。
VMIVME-2540
Features: Event counting – up to 4 GB event programming output – up to 24 discrete output boards with 15 MHz 68HC000 processor ANSI/IEEE standard 754-1985, used for 32-bit floating-point operations VMIVME-2540 is an intelligent digital input/output board with VMEbus slave interface, which can provide digital signal measurement and signal generation functions for 4, 8, 16, or 24 channels. These measurement and signal output functions are implemented by a series of AM9513A system timing controllers (STCs) and related interface logic. The onboard VMIVME-2540 local CPU (68HC000 microprocessor) provides a command driven user interface to execute circuit board functions, eliminating the need for users to directly program the system timing controller. Users configure measurement, timing, and output functions for each channel through a simple memory mapping interface composed of commands, command status, parameters, and return measurements. VMIVME-2540 is developed and produced by General Electric’s industrial automation production series. These models were subsequently purchased by Abaco Systems.
VMIVME-2540
This series, known as VMIC/GE Fanuc boards, is designed specifically for several applications in industrial production lines, such as CPU management and input output communication. VMIVME-2540 is one of the specific modules of the VMIC/GE Fanuc board, equipped with the function of operating as an intelligent counter controller. This device can count up to 4 gigabit events. It is equipped with a series of 24 discrete output channels that can be programmed through various onboard jumper module options. These jumpers can function at various extreme voltage levels, and 24 output channels are designed to provide 12 bit resolution. They can generate and absorb up to 10 milliamperes of current at a rate of+/-10V. In order to use VMIVME-2540 for offline testing, the analog input is designed to be disconnected from external circuits. The VMIVME-2540 module is designed with a VMEbus slave interface, which can provide digital signal measurement and signal generation capabilities for 4, 8, 16, or 24 channels. These possible measurement and signal output functions are applied by an integrated system timing controller array and a series of related interface logic.
VMIVME-2540
