特征：每个 8 位端口的方向可单独编程64 mA 灌电流能力（15 mA 拉电流）用于控制和数据寄存器的单独板地址解码用于故障检测和隔离的内置测试逻辑高可靠性 DIN 型 I/O 连接器8 位、16 位、32 位传输VMIVME-2510B 是 VMIC 超级模块系列的成员，该系列具有通用的编程功能。子系统可以配置 连续的 I/O地址以节省内存。这些产品（VMIVME-1110、VMIVME-2120、VMIVME-2130 和 VMIVME-2510B）都是经过精心设计的 具有两组板地址开关，可为 CSR 和 I/O 地址提供高效的内存地址映射。可以设置CSR地址开关，以便系统中各种板中的所有CSR都可以映射到连续的内存位置。Megamodule 产品还设计用于支持 8 位、16 位和 32 位数据传输。VMIVME-2510B 中设计了特定的硬件，以支持内置测试功能。VMIVME-2510B 支持离线和在线故障检测和隔离。
VMIVME-2510B
VMIVME-2510B是VMIC mega module系列的一员，该系列具有通用编程功能。子系统可以配置连续的I/O地址以节省内存。这些产品(VMIVME-1110、VMIVME-2120、VMIVME-2130和VMIVME-2510B)均设计有两组板地址开关，为CSR和I/O地址提供高效的存储器地址映射。可以设置CSR地址开关，使得系统中各种板之间的所有CSR可以被映射到连续的存储器位置。前面板故障 LED 用于指示此板上是否存在故障。上电或复位时，LED 亮起。成功完成板级诊断后，LED 可以熄灭。
VMIVME-2510B
Features: The direction of each 8-bit port can be individually programmed with 64 mA current injection capacity (15 mA pull current) for control and data registers, with separate board address decoding for fault detection and isolation. High reliability DIN type I/O connectors for 8-bit, 16-bit, and 32-bit transmission. VMIVME-2510B is a member of the VMIC super module series, which has universal programming functions. The subsystem can be configured with continuous I/O addresses to save memory. These products (VMIVME-1110, VMIVME-2120, VMIVME-2130, and VMIVME-2510B) are carefully designed with two sets of board address switches that provide efficient memory address mapping for CSR and I/O addresses. CSR address switches can be set so that all CSR in various boards in the system can be mapped to consecutive memory locations. The Megamodule product is also designed to support 8-bit, 16-bit, and 32-bit data transmission. Specific hardware is designed in VMIVME-2510B to support built-in testing functions. VMIVME-2510B supports offline and online fault detection and isolation.
VMIVME-2510B
VMIVME-2510B is a member of the VMIC mega module series, which has universal programming capabilities. The subsystem can be configured with continuous I/O addresses to save memory. These products (VMIVME-1110, VMIVME-2120, VMIVME-2130, and VMIVME-2510B) are designed with two sets of board address switches, providing efficient memory address mapping for CSR and I/O addresses. CSR address switches can be set so that all CSR between various boards in the system can be mapped to consecutive memory locations. The front panel fault LED is used to indicate whether there is a fault on this board. When powered on or reset, the LED lights up. After successfully completing board level diagnosis, the LED can be turned off.
VMIVME-2510B
